5.0 Inch Small LCD Touch Screen 720x1280 TFT Capacitive Touch Screen MIPI Interface
Product Details
| Display Type: | TFT LCD | Brightness: | 800 Cd/m² |
|---|---|---|---|
| Interface: | 30pin MIPI | Tft Active Area: | 61.776(H)*109.824(V)Mm |
| Operation Temp: | -20~ +70℃ | Touch Type: | Capacitive |
| Tft Lcd Type: | 5.0”TFT | Driver Ic: | HX8394-F |
| Highlight |
small lcd touch screen 720x1280,720x1280 tft capacitive touch screen,5.0 inch small lcd touch screen |
||
Product Description
5.0 Inch 720x1280 TFT Capacitive Touch Screen LCD Module With MIPI Interface For Industrial Applications
Product Description:
The Small LCD Touch Screen product also features a transmissive display mode that allows for better visibility and clarity in bright environments. With a luminance of 800nits, you can be sure that your display will remain clear and visible in any lighting condition.
Whether you need a display for your water purifier or other industrial applications, this Small LCD Touch Screen product is perfect for you. It offers a resolution of 720x1280, providing a high-quality display for your content. With an all-viewing angle, you can be sure that your display will be visible from any angle.
Additionally, this product can operate in temperatures ranging from -20~ +70℃, making it suitable for use in various environments. This ensures that your display will remain functional and reliable even in harsh conditions.
In conclusion, the Small LCD Touch Screen product is the perfect choice for your display needs. With its capacitive touch type, transmissive display mode, 5.0” TFT LCD type, all-viewing angle, -20~ +70℃ operation temperature, and 720x1280 resolution, it is a highly-functional and reliable display solution for various applications, including water purifier, POS machine displays.
Features:
- Product Name: Small LCD Touch Screen
- Dot Arrangement: 720×3(RGB)×1280 Dots
- Interface: 30pin MIPI
- Operation Temp: -20~ +70℃
- Display Type: TFT LCD
- Viewing Angle: All
- Application: Water purifier display
- Display Type: TN display
- Luminance: 800nits
Technical Parameters:
| Display Mode | Transmissive |
| Storage Temp | -30~ +80℃ |
| Tft Lcd Type | 5.0”TFT |
| Operation Temp | -20~ +70℃ |
| Touch Type | Capacitive |
| Driver Ic | HX8394-F |
| LCM Outline Size | 64.76*118.70*2.05Mm |
| Dot Arrangement | 720×3(RGB)×1280 Dots |
| Tft Active Area | 61.776(H)*109.824(V)Mm |
| Brightness | 800 Cd/m² |
The Small LCD Touch Screen product has a luminance of 800nits and features a capacitive touch screen. It is suitable for use in a water purifier display.
Applications:
The TFT LCD type of this product is 5.0”TFT with a dot arrangement of 720×3(RGB)×1280 dots. The interface used in this product is a 30pin MIPI. The storage temperature for this product ranges from -30~ +80℃. The brightness of this product is 800 Cd/m².
This small LCD touch screen product is suitable for a variety of applications. It can be used in industrial control systems, medical equipment, handheld devices, and many more. The TN display of this product provides a clear and sharp image with a resolution of 720x1280. The capacitive touch screen of this product is highly responsive and user-friendly, making it perfect for applications that require touch input.
Whether you need a small LCD touch screen for your industrial control system or medical equipment, the OEM FLR-T107HS500 is an excellent choice. With its high-quality display and responsive touch screen, this product is sure to meet your needs.
FAQ:
Q: What is the brand name of this small LCD touch screen product?
A: The brand name of this product is OEM.
Q: What is the model number of this small LCD touch screen product?
A: The model number of this product is FLR-T107HS500.
Q: Where is this small LCD touch screen product manufactured?
A: This product is manufactured in China.
Q: Does this small LCD touch screen product have any certifications?
A: Yes, this product is ROHS certified.
Q: What is the minimum order quantity for this small LCD touch screen product?
A: The minimum order quantity for this product is 1 piece.
Q: What is the price of this small LCD touch screen product?
A: The price of this product is negotiated.
Q: What are the packaging details for this small LCD touch screen product?
A: The packaging details for this product are carton packing.
Q: What is the delivery time for this small LCD touch screen product?
A: The delivery time for this product is 7-15 working days.
Q: What are the payment terms for this small LCD touch screen product?
A: The payment terms for this product are T/T.
Q: What is the supply ability of this small LCD touch screen product?
A: The supply ability of this product is 300k per month.
