Detail Information

Type:	TN	Display Size:	2.8 Inch
Supplier Type:	LCD Panel	Display & LCD Type:	240* RGB *320
Viewing Direction:	12 O 'clock	Interface Type:	SPI
Touch Panel:	Optional	Outline Dimemsions (mm):	5069.203.6mm
Driver IC:	ILI9341	Backlight Type:	White LED
PIN:	18
Highlight:	2.8 inch tft lcd display , ili9341 tft lcd display , ili9341 lcd display screen

Product Description

1.Display Type:	2.8inch TFT LCD ILI9341
2.Display mode:	Transmissive
3.Resolution:	2.8" 240(RGB)320
4. Number of colors:	262K
5.Outline Dimensions:	50.0069.23.6mm
6.Driver IC:	ILI9341
7.Interface Type:	SPI
8.Baclight:	White 4 LED Series
9.Operating voltage:	+2.8V~3.3V
10.Viewing Angle:	12 O'clock
11.Operating Temp:	-20°C~+70°C
12.Storage Temp:	-30°C~+80°C
